LNE-12V100WAAA Delta CC CV LED Driver – 100W 12V 8000mA Non-Dimming-Fast Shipping

Description

Delta LNE-12V100WAAA CC + CV LED Driver, 100W Max Output Power, 120-277Vac input, adjustable output up to 12Vdc and 8000mA, Non-dimmable

Delta 100W CC + CV Adjustable LED Driver

Adjustable, Enabling Hundreds of Configurations – potentiometers to adjust constant voltage (CV) & constant current (CC) levels

Output Current Range: 4000-8000mA

Output Voltage Range: 6-12Vdc in CC mode and 10.8-13.5Vdc in CV mode

Dimming Controls: Non-Dimming

IP65 and UL Dry Location

High surge immunity (common mode: 6kV, differential mode: 4kV)
