EUM-100S053DG Inventronics Constant-Current-Programmable LED Driver – 100W 530mA Dimmable-Fast Shipping

Description

Inventronics EUM-100S053DG Constant Current LED Driver, 100W Max Power Output, Universal 120-277V Input, Programmable 350-530mA (factory set at 530mA) Output Current, 94-286V Output, Analog/PWM/Timer Dimming

Inventronics 100W Constant Current LED Driver

Programmable, Enabling Hundreds of Configurations 350mA to 530mA (factory default 530mA)

Compact Metal Case with Excellent Thermal Performance

Dimming Controls: Isolated 1-5V/1-10V/10V PWM/3-Timer-Modes Dimmable

Input Surge Protection: DM 6kV, CM 10kV

Output Lumen Compensation

Class 2 and SELV Output

IP66 / IP67 and UL Dry / Damp / Wet Location

TYPE HL, for use in a Class I, Division 2 hazardous (Classified) location

UL Recognized

Spec Sheets

Inventronics EUM-100S053DG Specs
